Pinarello New Dogma F Disc Sram Red AXS 12-speed road bike Princeton Peak 4550 G117 Starry Red

The Dogma F Disc SRAM Red AXS E1 12v Princeton Peak 4550 G117 Starry Red Pinarello is a true competition machine, developed with a clear objective in mind: to combine lightness, aerodynamics, stiffness and handling precision at the very highest level. Its TorayCa M40X carbon frame, used notably on professional team bikes, delivers excellent lateral stiffness whilst maintaining a remarkably low weight.

The Dogma F features an advanced aerodynamic design with a completely redesigned down tube, a tapered head tube and a new Aero-Keel bottom bracket shell. The down tube is slightly angled to improve aerodynamic performance around the bottom bracket. The new ONDA fork with ForkFlap technology, combined with integrated thru-axles and a fully concealed seatpost clamp, helps to reduce drag whilst maintaining precise and stable handling at high speeds.

The integrated MOST Talon Ultra Fast cockpit completes this design with a lighter, more aerodynamic profile. Its carefully engineered position allows the rider to adopt a more efficient riding position whilst maintaining excellent control over the bike. The ONDA fork, with its 47 mm rake, has also been developed to offer a precise balance between manoeuvrability, stability and speed on descents.

This version is fitted with the prestigious SRAM Red eTap AXS 12-speed groupset, which combines wireless electronic shifting, rapid gear changes and high-end hydraulic braking. The build is completed by Princeton Peak 4550 carbon wheels, recognisable by their wavy rim profile designed to optimise aerodynamics and stability.

Technical specifications:

Frame:

- Frame: Pinarello Dogma F made from TorayCa M40X carbon, eTiCR internal cable routing, Italian bottom bracket, UCI-approved
- Fork: Pinarello ONDA eTICR carbon fork with ForkFlap technology, 1.5" tapered steerer tube

Drivetrain:

- Groupset: SRAM Red eTap AXS E1 12-speed
- Crankset: SRAM Red eTap AXS 12-speed
- Front derailleur: SRAM Red eTap AXS 12-speed
- Rear derailleur: SRAM Red eTap AXS 12-speed
- Cassette: SRAM Red XG-1290
- Chain: SRAM Red 12-speed
- Bottom bracket: SRAM Red

Brakes:

- Brakes: SRAM Red 2-piston hydraulic brakes
- Discs: 160 mm front / 160 mm rear

Components:

- Handlebars / Integrated stem: MOST Talon Ultra Fast
- Saddle: MOST Lynx Ultrafast Superflow L Carbon 145 mm
- Seatpost: Pinarello Aero Seatpost with 3D titanium clamp
- Bottle cage: Pinarello Trap PACF + bottle Pinarello Fly 550 ml

Wheels:

- Wheels: Princeton Peak 4550 evolution
- Rim height: 45 mm at the front and 50 mm at the rear
- Tyres: Continental Grand Prix 5000 S TR 700x28 Tubeless Ready

General information:

- Colour: G117 Starry Red
- Sizes: 43 – 46.5 – 50 – 51.5 – 53 – 54 – 55 – 56 – 57.5 – 59.5 – 62
- Weight: 6.63 kg (size 53, without pedals)
- Brand: Pinarello
