Vélo route Pinarello New Dogma X Sram Red AXS 12v Princeton Grit 4540 J120 Moonlight Frost

The Pinarello New Dogma X SRAM Red AXS 12v Princeton Grit 4540 J120 Moonlight Frost is a top-of-the-range road bike designed for cyclists looking to combine speed, performance and comfort over long distances. Its TorayCa M40X carbon fibre frame offers an exceptional balance between lightness, stiffness and responsiveness, whilst ensuring excellent vibration damping. X Stays 2.0 technology, combined with the asymmetrical design unique to Pinarello, optimises power transfer whilst ensuring stable, precise and dynamic handling.

Thanks to its Endurance geometry, the Dogma X offers a more comfortable riding position without compromising the sporty feel of a true competition bike. The fully integrated cable routing improves aerodynamics and provides a sleek finish, whilst the clearance for tyres up to 35 mm enhances comfort, grip and versatility on all types of road. The result is a bike that offers a smooth, confident and efficient ride on both long climbs and fast sections.

This version is fitted with the SRAM Red AXS 12-speed electronic groupset, renowned for its speed, precision and reliability in all conditions. The Princeton Grit 4540 DB carbon wheels offer an excellent balance between efficiency, lightness and stability, whilst the Pirelli P ZERO Race TLR 35 mm tyres enhance comfort and control without compromising performance. With its integrated MOST Talon Ultra Light cockpit and MOST Lynx Ultrafast Superflow carbon saddle, this Dogma X embodies excellence Pinarello and offers an exceptional riding experience, whether over long distances or on the most demanding routes.

Technical specifications:

Frame & Fork:

- Frame: TorayCa M40X with Nanoalloy technology, asymmetric design Pinarello X, X Stays 2.0 technology, fully integrated cable routing, Italian bottom bracket, UCI-approved, compatible with tyres up to 35 mm
- Fork: TorayCa M40X, carbon fork with internal cable routing, optimised for disc brakes

Drivetrain:

- Shifters: SRAM Red eTap AXS, 12-speed
- Front derailleur: SRAM Red eTap AXS, 12-speed
- Rear derailleur: SRAM Red eTap AXS, 12-speed
- Crankset: SRAM Red eTap AXS, 12-speed
- Cassette: SRAM Red XG-1290, 12-speed
- Chain: SRAM Red eTap AXS, 12-speed
- Bottom bracket: SRAM Red, Italian standard

Braking:

- Brakes: SRAM Red hydraulic, 2-piston caliper
- Discs: Sram Centerline 160 mm

Wheels & Tyres:

- Wheels: Princeton Grit 4540 DB carbon
- Tyres: Pirelli P ZERO Race TLR, 700x35 mm
- Axles: Ultra Light Custom Axle, 12x100 mm at the front and 12x142 mm at the rear, tool-free removal
- Maximum tyre clearance: 35 mm

Components:

- Handlebars: MOST Talon Ultra Light integrated one-piece carbon
- Saddle: MOST Lynx Ultrafast Superflow L Carbon, width 145 mm
- Seatpost: Pinarello Aero with 3D clamp and TwinForce titanium clamping mechanism

Accessories:

- Bottle cage: Pinarello TRAP PACF Ø74 mm
- Water bottle: Pinarello Fly 550 ml black

General information:

- Geometry: Endurance
- Size: 43 - 46.5 - 50 - 51.5 - 53 - 54 - 55 - 56 - 57.5 - 59.5 - 62
- Colour: J120 Moonlight Frost
- Brand: Pinarello
