DT Swiss F 232 ONE Lever 29-inch MTB fork

44mm or 51mm offset - 100, 110 or 120mm travel - XC use

I choose my options

Colours

Axle fork

Clearance

Fork offset

Wheel

MPN : F232ODHLOGAS26812S | EAN : 7613052370637 | Ref : 18794880004
€872.85
Price : €979.90
Dispatch within 4 to 6 days

DT Swiss F 232 ONE Lever 29-inch MTB fork

More details Dispatch within 4 to 6 days

DT Swiss F 232 ONE Lever 29-inch MTB fork

€872.85
Our advice

Alexandre La.

Rider Elite XC for 5 years

The DT Swiss 232 ONE Lever fork is the Swiss brand's new fork for cross-country riding, available with 100 to 120 mm of travel, ideal for technical and difficult trails. You can choose this fork with a different offset, with a choice of 44 mm or 51 mm. This option allows you to change the dynamics of the bike to suit your needs.

Featuring INCONTROL technology, this model has three suspension modes that can be adjusted directly from the fork. OPEN mode allows you to descend at speed, while DRIVE mode offers medium damping to ensure performance on difficult and technical climbs. Finally, with LOCK mode, you will have no damping, but full efficiency for sprinting or rolling sections. The 232 ONE Lever offers an impressive weight-to-stiffness ratio, thanks to the optimised design of the fork legs. From the choice of materials to their arrangement on the fork, everything has been designed to offer you the best possible performance. The F 232 One is also equipped with the APT (Adaptable Progression Tune) system, which allows you to adjust the progressiveness of the spring curve according to your riding style and the terrain.

Extremely practical to use and maintain, no tools are required to adjust the compression and rebound of the fork. Unlike the previous version, it is now directly integrated.

Technical specifications:

- Colour: Black - Weight: 1510g max - Max. system weight: 130 kg (MTB) / 120 kg (e-MTB) - ASTM classification: 3- Wheel diameter: 29" / 700c - Travel: 100mm, 110mm, 120mm - Offset: 44mm, 51mm - Spring technologies: Linear / APT- Damping technology: Incontrol - Actuation: Lever (lockout on the fork steerer) - Piston diameter: 32 mm - Brake caliper mounting type: PM 6"- Pivot: Tapered 1.5" - 1 1/8" - Axle system: RWS Thru Axle 15 mm - Centre distance: Boost 110 mm - Pivot: Aluminium- Brand: DT Swiss Technology details: LINEAIR: Dual chamber system equipped with a bypass, designed for cross-country riding. Provides sensitivity to small bumps, excellent mid-stroke support and progressive end-of-stroke performance. IN CONTROL: The INCONTROL system opens and closes the CHV and CBV channels to regulate oil flow and, consequently, the level of compression. The suspension can thus be customised for all circumstances. This system offers 3 settings: Open, Drive and Lock. Open mode is ideal for descents with ultra-responsive and precise damping. Drive is the intermediate position. It absorbs the biggest bumps in the terrain while maintaining firmness for optimised pedalling efficiency. Finally, Lock mode stiffens everything for total power transfer.

APT: The spring curve can be adjusted to suit the circuit and the rider's riding style. Remove or add shims in the fork's air chamber to find the desired setting.

OPTIMISED ARCHITECTURE: The F 232 ONE benefits from an improved architecture that optimises the position of materials in specific load and stress areas. This technology offers an excellent weight-to-stiffness ratio.

Colours black
Axle fork 15x110mm (Boost)
Clearance 110mm
Fork offset 51mm
Wheel 29
EAN 7613052370637
Supplier reference F232ODHLOGAS26812S

Colours Axle fork Clearance Fork offset Wheel Availability Price Supplier reference EAN
Web Stores
black15x110mm (Boost)100mm44mm29Dispatch within 4 to 6 daysSold out€872.85F232OCILOGAS35775S7613052324500
black15x110mm (Boost)100mm51mm29Dispatch within 4 to 6 daysSold out€872.85F232OCHLOGAS26802S7613052370613
black15x110mm (Boost)110mm44mm29Dispatch within 4 to 6 daysSold out€872.85F232ODILOGAS35778S7613052324524
black15x110mm (Boost)110mm51mm29Dispatch within 4 to 6 daysSold out€872.85F232ODHLOGAS26812S7613052370637
black15x110mm (Boost)120mm44mm29Dispatch within 4 to 6 daysSold out€872.85F232OEILOGAS35782S7613052324548
black15x110mm (Boost)120mm51mm29Dispatch within 4 to 6 daysSold out€872.85F232OEHLOGAS26815S7613052370651
