DT Swiss R 535 ONE Lever Standard shock absorber

190x40, 190x45, 210x50, 210x55, 230x60, 230x65 - All-mountain use

I choose my options

Centre distance/stroke

Type of shock absorber mounting

MPN : C535ODMECESA44820S | EAN : 7613052562094 | Ref : 18794970002
€395.80
Price : €448.00
Dispatch within 4 to 6 days

DT Swiss R 535 ONE Lever Standard shock absorber

More details Dispatch within 4 to 6 days

DT Swiss R 535 ONE Lever Standard shock absorber

€395.80
Our advice

The top-of-the-range all-mountain shock absorber from DT Swiss. Extremely versatile, it ensures efficiency on climbs, power transfer on flat sections, and maximum damping on fast and/or technical descents.

Alexandre La.

Rider Elite XC for 5 years

If you're an all-mountain trail enthusiast, you need a high-quality shock absorber with exceptional versatility. That's where the DT Swiss R 535 ONE Lever Standard comes in, a high-end shock absorber equipped with a bypass in the air chambers. It offers superior comfort by absorbing small shocks, but remains ultra-high-performance by providing mid-stroke support and end-stroke progressivity. Featuring INCONTROL technology, the shock absorber has three damping modes. You can adjust the shock absorber's compression level using its lever, ensuring efficiency whatever the terrain. Whether on flat ground, uphill or downhill, the LOCK, DRIVE and OPEN programmes offer everything you need to ride smoothly. Before purchasing, please check the compatibility of your frame's centre distance/travel.Recommended use:

- All-mountain

Technical specifications:

- Material: Aluminium - Shock absorber mounting: Standard - Suspension system: LINEAIR - Shock absorption system: INCONTROL- Bearing type: DU bushing - Centre distance/travel: 190x40, 190x45, 210x50, 210x55, 230x60, 230x65 - Compression and rebound adjustment: Medium-Medium- Remote: Lever - Weight (190x40): 300g Technologies: - INCONTROL: The INCONTROL system opens and closes the CHV and CBV channels to regulate oil flow and, consequently, the level of compression. This allows the suspension to be tailored to suit all circumstances. The system offers three settings: Open, Drive and Lock. Open mode is ideal for descents, with ultra-responsive and precise damping. Drive is the intermediate position. It absorbs the biggest bumps in the terrain while maintaining firmness for optimised pedalling efficiency. Finally, Lock mode stiffens everything for total power transfer.
- LINEAIR: When the shock absorber is fully relaxed, the pressure in the positive chamber is lower than that in the negative chamber. The take-off force is low, and traction and sensitivity are perfectly optimised. During compression, the piston passes over the chamber bypass. When the piston is on the bypass, it balances the pressure in the chambers. When the shock absorber is compressed further, only the air in the positive chamber is compressed and the negative chamber is depressurised.

Centre distance/stroke 190x45mm
Type of shock absorber mounting Standard
EAN 7613052562094
Supplier reference C535ODMECESA44820S

Centre distance/stroke Type of shock absorber mounting Availability Price Supplier reference EAN
Web Stores
190x45mmStandardDispatch within 4 to 6 daysSold out€395.80C535ODMECESA44820S7613052562094
230x60 mmStandardDispatch within 4 to 6 daysSold out€395.80C535OMGECESA44823S7613052562124
190x40mmStandardDispatch within 4 to 6 daysSold out€395.80C535ODLECESA44819S7613052562087
210x50mmStandardDispatch within 4 to 6 daysSold out€395.80C535OJDECESA44821S7613052562100
230x65mmStandardDispatch within 4 to 6 daysSold out€395.80C535OMJECESA44824S7613052562131
210x55mmStandardSold outSold out€395.80C535OJEECESA44822S7613052562117
