Vélo route Trek Madone SL 5 Pro 8e Gen Shimano 105 12v Bontrager Aeolus Elite 48 Gloss Dark Star Matte Deep Smoke 2027

The Trek Madone SL 5 Pro 8th Gen Shimano 105 12v Bontrager Aeolus Elite 48 Gloss Dark Star Matte Deep Smoke 2027 is designed for cyclists who want to experience the performance of the Madone range with a reliable, high-performance build. Its OCLV 500 Series carbon frame incorporates the key innovations developed for the brand’s top-of-the-range models. Thanks to IsoFlow technology, it effectively combines lightness, stiffness and vibration damping to deliver excellent performance whilst maintaining a high level of comfort on long rides. Its responsive and precise handling makes it equally suited to tackling climbs and maintaining high speeds on the flat.

This eighth-generation Madone features fully optimised aerodynamics thanks to Full System Foil profiles, neat cable integration and ‘ Race ’ geometry, which strikes an excellent balance between stability and responsiveness. The frame accommodates tyres up to 32 mm, offering greater comfort, grip and versatility depending on the terrain. The full-carbon fork completes the package, ensuring precise steering and excellent control, even on the fastest sections.

This model is fitted with the Shimano 105 12-speed mechanical drivetrain, renowned for its reliability, precision and smooth gear changes, making it ideal for both intensive training and competition. The Aeolus Elite 48 carbon wheels Bontrager offer an excellent balance between aerodynamics, stiffness and stability, favouring high speeds whilst remaining effective during accelerations. Combined with the Bontrager Comp cockpit, the Bontrager Aeolus Elite saddle and components carefully selected by Trek, they enable the Madone SL 5 Pro to deliver top-level performance with excellent value for money.

Technical specifications:

Frame & Fork:

- Frame: OCLV Carbon 500 Series, Full System Foil tube shape, IsoFlow seat tube, RCS headset, electronic or mechanical cable routing, removable aerodynamic chain guard, T47 bottom bracket, Flat Mount disc brakes, UDH universal derailleur hanger, 142 x 12 mm thru-axle
- Fork: 8th-gen Madone full-carbon, carbon tapered steerer, internal brake cable routing, Flat Mount disc brakes, 12 x 100 mm fluted thru-axles

Drivetrain:

- Shifters: Shimano 105 R7100, 12-speed
- Front derailleur: Shimano 105 R7100, towed-on, Down Swing technology
- Rear derailleur: Shimano 105 R7100, compatible with cassettes up to 36 teeth
- Crankset: Shimano 105 R7100, 50/34 teeth (lengths vary by size)
 - Cassette: Shimano 105 7101, 11-34, 12-speed
- Chain: Shimano SLX M7100, 12-speed
- Bottom bracket: T47 threaded, internal bearings

Brakes:

- Brakes: Shimano 105 hydraulic disc brakes, Flat Mount
- Rotors: Centrelock-compatible, maximum diameter 180 mm at the front and 160 mm at the rear

Wheels & Tyres:

- Wheels: Bontrager Aeolus Elite 48, carbon, Tubeless Ready, 48 mm profile, 12 x 100 mm thru-axle at the front and 12 x 142 mm at the rear
- Freehub body: Shimano 12-speed
- Tyres: Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120 tpi, 700 x 28 mm
- Maximum tyre clearance: 32 mm

Components:

- Handlebar: Bontrager Comp, aluminium, diameter 31.8 mm, depth 80 mm, height 121 mm (width adjusted according to frame size)
- Stem: Trek RCS Pro, -7°, length adjusted to frame size
- Saddle: Bontrager Aeolus Elite, austenitic rails, width 145 mm
- Seatpost: Madone Aero carbon, offset 0 mm, short version
- Handlebar tape: Trek Gel Cork

General information:

- Maximum weight: 125 kg (bike + rider + accessories)
- Sizes: XS, S, M, ML, L, XL
- Colours: Gloss Dark Star, Matte Deep Smoke / Black
- Brand: Trek
