Trek ’s Madone SL 6 8th Gen SRAM Rival AXS 12v Bontrager Aeolus Elite 50 Gloss Fury Red Matte Deep Smoke is a road bike designed for cyclists who want to ride fast whilst enjoying a high level of comfort over long distances. Its OCLV 500 Series carbon frame incorporates the latest innovations developed by Trek, notably IsoFlow technology, which enhances vertical compliance without compromising the frame’s stiffness. This design results in a responsive, precise and particularly enjoyable bike to ride, capable of excelling in both training rides and competitions.
The 8th generation of the Madone adopts a holistic aerodynamic approach with Full System Foil tubes, fully integrated cable routing and ‘ Race ’ geometry, offering a perfect balance between efficiency and stability. The T47 bottom bracket optimises power transfer, whilst the clearance for tyres up to 32 mm improves comfort, grip and versatility on all types of terrain. The full-carbon fork also contributes to precise handling and provides excellent control on fast descents and when changing pace.
This version is fitted with the SRAM Rival AXS E1 12-speed electronic drivetrain, renowned for its fast gear changes and high reliability. The Bontrager Aeolus Elite 50 carbon wheels, with their 50 mm profile, offer excellent aerodynamic performance whilst maintaining good stability as speed increases. Combined with the Trek RCS cockpit, the Bontrager Aeolus Elite saddle and the brand’s top-of-the-range components, they enable the Madone SL 6 8th Gen to deliver dynamic, efficient and exceptionally versatile handling, ideal for cyclists seeking a fast, modern bike ready to perform on all terrains.
Technical specifications:
Frame & Fork:
- Frame: OCLV Carbon 500 Series, Full System Foil tube shape, IsoFlow seat tube, RCS headset, electronic or mechanical cable routing, removable aerodynamic chain guard, T47 bottom bracket, Flat Mount disc brakes, universal derailleur hanger (UDH), 142 x 12 mm thru-axle
- Fork: 8th-generation all-carbon Madone, carbon tapered steerer tube, internal cable routing, Flat Mount mount, 12 x 100 mm threaded thru-axle
Drivetrain:
- Shifters: SRAM Rival AXS E1, 12-speed
- Front derailleur: SRAM Rival AXS, brazed-on
- Rear derailleur: SRAM Rival AXS, compatible with cassettes up to 36 teeth
- Crankset: SRAM Rival AXS DUB 48/35 (165 mm for sizes M, ML / 170 mm for sizes L, XL)
- Cassette: SRAM XG-1250, 10-36, 12-speed
- Bottom bracket: SRAM DUB, T47 threaded, internal bearings
- Battery: SRAM AXS (charger included)
Brakes:
- Brakes: Discs SRAM Paceline Centrelock, 160 mm front / rear
- Compatibility: Maximum disc size: 180 mm at the front / 160 mm at the rear
Wheels & Tyres:
- Wheels: Bontrager Aeolus Elite 50 in OCLV carbon, Tubeless Ready, 12 x 100 mm thru-axle at the front and 12 x 142 mm at the rear, SRAM XDR freehub body
- Tyres: Bontrager Aeolus Pro Tubeless Ready , flexible aramid bead, 120 TPI, 700x28 mm
- Tyre compatibility: Up to 32 mm
Components:
- Handlebars: Bontrager aluminium composite 31.8 mm (reach 80 mm / drop 121 mm) or Bontrager Aero Pro OCLV Carbon depending on build (width adapted to each size)
- Stem: Trek RCS (-7°) (80 mm for XS / 90 mm for S, M / 100 mm for ML, L / 110 mm for XL)
- Saddle: Bontrager Aeolus Elite, austenitic rails, width 145 mm
- Seatpost: Madone Aero, offset 0 mm, short version
- Handlebar tape: Trek EcoTack / Trek Gel Cork
General information:
- Weight: 8.11 kg (size ML, with TLR sealant, without inner tubes)
- Max. load: 125 kg (bike + rider + luggage)
- Sizes: XS, S, M, ML, L, XL
- Colours: Fury Red Matte Deep Smoke / Red
- Brand: Trek
