Road bike Pinarello F5 MY26 105 Di2 12v Ultrafast 45 DB H220 Etna Black Matt

Renowned for its heritage in major races such as the Tour de France, Pinarello brings its expertise to a more accessible model with the F5 MY26. Built on a Torayca T700 UD carbon frame, it offers the perfect balance of stiffness, responsiveness and comfort for covering the miles, whether in the mountains or on the flat.

When it comes to drivetrain, the new Shimano 105 Di2 12-speed groupset guarantees precise and reliable gear changes in all conditions. The hydraulic disc brakes offer optimal control even on the most demanding descents. Finally, the versatile Most Ultrafast 45 wheels, fitted with Pirelli P7 tyres, complete this high-performance build designed for speed and endurance.

Technical specifications

Frame:

- Frame: Torayca T700 UD, TiCR internal cable routing, Italian bottom bracket, UCI-approved
- Fork: Onda Carbon

Drivetrain:

- Crankset: Shimano 105 Di2
- Cassette: Shimano 105 Di2 12-speed
- Chain: Shimano 105 Di2
- Shifters: Shimano 105 Di2
- Front derailleur: Shimano 105 Di2
- Rear derailleur: Shimano 105 Di2

Braking:

- Brakes: Shimano 105 dual-piston
- Discs: Shimano 105, 160 mm front and rear

Components:

- Stem: CLAW ULTRA AERO ALU
- Handlebar: JAGUAR CLAW ULTRA ALU
- Saddle: Most Lynx My26
- Seatpost: fsc frontal seat clamp

Wheels:

- Wheels: Most Ultrafast 45
- Tyres: Pirelli P7

General information:

- Colour: Dark green
- Sizes: 46.5, 50, 51.5, 53, 54.5, 56, 57.5, 59.5
- Weight: 8.60 kg

Geometry:

(mm)	43	46.5	50	51.5	53	54.5	56	57.5	59.5
A	502.5	517.7	525.5	532.3	542.6	557.9	570.3	599.3	633.5
B	351.3	365.2	372.1	378.1	385.6	388.3	390.8	395.4	400.3
C	97	104	109	114	123	138	149.5	178	220
D	425	450	465	485	500	515	525	560	580
E	500	515	525	535	545	555	565	578	600

Geometry:

(mm)	43	46.5	50	51.5	53	54.5	56	57.5	59.5
A	502.5	517.7	525.5	532.3	542.6	557.9	570.3	599.3	633.5
B	351.3	365.2	372.1	378.1	385.6	388.3	390.8	395.4	400.3
C	97	104	109	114	123	138	149.5	178	220
D	425	450	465	485	500	515	525	560	580
E	500	515	525	535	545	555	565	578	600
