Inspyre Concorde V3 Orange / Gun Metal BMX Cruiser Frame/Fork Kit

The Inspyre Concorde V3 Cruiser is a must-have for BMX riders Race looking for performance, rigidity and precision. Designed for the Cruiser categories, this frame + fork kit benefits from Inspyre's expertise and advanced engineering dedicated to competition.

Each tube of the frame is precision hydroformed, achieving a perfect balance between lightness, strength and aerodynamics. The strategic area linking the downtube, bottom bracket and rear chainstays has been completely redesigned to optimise power transmission and provide exceptional lateral rigidity.

The result is maximum energy return with every pedal stroke, ideal for explosive starts and corner exits.

The finish matches the performance, with flat welds for a top-of-the-range appearance and stickers applied under varnish for optimum durability.

On the rear side, the SWELL V2 dropouts offer a 25 mm adjustment range, allowing precise adjustment of chain tension. The internal 7075-T6 aluminium plates remain in place when the wheel is removed, facilitating maintenance.

The APEX Carbon fork completes this kit with a multi-fibre design that effectively manages torsional stress, impacts and lateral loads. Its 7075-T6 aluminium steerer tube and CNC machined dropouts guarantee strength and precision.

Designed for competition, the Concorde V3 is compatible with current standards and ensures consistent performance on the most demanding tracks.

Technical specifications :

Frame:
- Colour: Orange / Gun Metal
- Sizes: Cruiser Pro XL and Cruiser Pro XXL
- Material: Aluminium AL66
- Multi-thickness hydroformed tubes
- Welds: Flat weld (top-of-the-range finish)
- Headset:
- Standard: IS42/IS42 & IS42/IS52
- Bottom bracket:
- BSA 68 or BB86 depending on size
- Brakes:
- Compatible with Post Mount hydraulic brakes
- 120 mm disc (140 mm with adapter)
- Rear drop-outs:
- SWELL V2 with 25 mm adjustment range
- 7075-T6 aluminium inserts
- Axle:
- Compatible with 15 mm thru axle
- 10 mm adapters supplied

Forks:
- Model: APEX Carbon
- Construction: multi-directional carbon fibre
- Pivot: 7075-T6 aluminium
- Drop-outs: CNC
- Axle:
- 10 mm (Junior to Expert XL)
- 20 mm (Pro and Cruiser)

Compatibility:
- ADS Inspyre chain tensioner
- Headset Pride Racing recommended
