Designed to go fast, very fast, the Teammachine R 01 Five embodies the racing DNA of BMC in its most accomplished form. Developed with the expertise of Red Bull Advanced Technologies, it has been designed to offer a real aerodynamic advantage, perceptible from the very first accelerations.

Its 01 Premium Carbon frame combines lightness and extreme rigidity, with a precise distribution of reinforcement zones to maximise power transfer. Every watt is exploited, every acceleration is clean. The wide-spaced fork channels airflow and stabilises the front wheel at high speeds, for measurable aerodynamic gains.

The Shimano 105 Di2 12-speed drivetrain ensures fast, precise gear changes. The 50 mm CR 50 carbon wheels, mounted tubeless with 28 mm Pirelli P Zero Race TLR tyres, maintain speed and optimise performance on rolling terrain.

With its fully adjustable ICS2 integrated cockpit and Aerocore design, this Teammachine R 01 Five is a machine cut out for competition, aimed at cyclists looking for a modern, rigid and resolutely performance-oriented aerodynamic platform.

Technical specifications :

Frame :

- Frame: Teammachine R 01 Premium Carbon with Aerocore design and internal cable routing, Flat Mount disc brakes, 12 x 142 mm thru axle
- Fork: Teammachine R 01 Premium Carbon, Flat Mount disc brakes and 12 x 100 mm thru axle

Peripherals :

- Stem: BMC ICS2 with integrated cockpit technology
- Handlebars: BMC HB D4 01 aluminium (135 mm height, 70 mm length, 6° opening angle)
- Teammachine R 01 Premium Carbon seatpost( 0 mm offset for sizes 47 to 51 and 15 mm offset for sizes 54 to 61)
- Saddle: Selle Italia SLR Advan 145mm with tubular steel rails
- Bottle carrier: Aerocore

Drivetrain :

- Rear derailleur: SHIMANO 105 Di2 RD-R7150
- Front derailleur: SHIMANO 105 Di2 FD-R7150
- Levers: SHIMANO 105 Di2 ST-R7170
- Crankset: SHIMANO 105 FC-R7100 52-36 teeth
- Cassette: SHIMANO CS-HG710 11-36 teeth
- Chain: SHIMANO CN-M6100
- Bottom bracket: SHIMANO Press-Fit BB-RS500-PB

Braking :

- Brake levers/calipers: SHIMANO 105 BR-R7170
- Discs: SHIMANO 105 RT-CL700 160mm / 160mm

Wheels :

- Rims: CR 50 Carbon Tubless Ready
- Rim height: 50 mm
- Hubs: TXC-812 & TXC-240A Center Lock
- Tyres: Pirelli P Zero Race TLR
- Tyre width: 28 mm

Additional information :

- Sizes: 47 - 51 - 54 - 56 - 58 - 61
- Brand: BMC
- Colour: Red
- Weight: 8.0 kg in size 54
- Weight limit: 110 kg
- ASTM classification: Level 2

Geometry :

(mm)	47	51	54	56	58	61
A	504	528	548	563	582	608
B	368	378	387	393	402	409
C	108	133	149	165	185	211
D	418	463	499	519	541	570
E	522	532	552	562	582	598
