Mavic Crossmax S Carbon 29-inch MTB wheels

The Mavic Crossmax S Carbon 29 brings the responsiveness and precision of carbon to cross-country and light trail riding. Thanks to Adaptive Layup technology, the rim is reinforced at strategic points whilst remaining lightweight elsewhere, offering responsive, efficient wheels designed for fun.

The Instant Drive 360 freehub system ensures fast and reliable engagement and is easy to maintain, whilst the Infinity hubs optimise power transfer. Combined with UST Tubeless Ready technology, this wheelset is synonymous with performance, reliability and ease of use.

Technical specifications:

- Discipline: XC, light trail (ASTM category 3)
- Compatible tyres:
- Min.: 2.10" (max. pressure 2.95 bar / 43 PSI)
- Max.: 3.00" (max. pressure 1.95 bar / 28 PSI)
- Maximum system weight (bike + rider): 150 kg

Weight: 1695 grams per pair (790 g for the front wheel / 905 g for the rear wheel)

Hubs:
- Freewheel technology: Instant Drive 360 (24 or 40 teeth)
- Bearings: QRM Auto, sealed cartridge
- Front axle: 15x110 mm
- Rear axle: 12x148 mm
- Body: Aluminium, Classic design
- Compatibility: Shimano HG MTB, Shimano MS, Sram XD MTB
- Disc standard: 6-hole or Center Lock®

Spokes:
- Material: Steel
- Shape: bent, round
- Lacing: crossed in pairs (front and rear)
- Nuts: Steel, ABS, black

Rim:
- Material: 100% carbon fibre
- Internal width: 30 mm
- Profile: hookless
- ETRTO size: 622x30TSS
- Hole pattern: 24 holes (front and rear)
- Tyre type: UST Tubeless Ready
- Braking system: disc

Accessories included: User guide, Rim tape fitted to the wheel, UST valve (not fitted), 2 spare spokes, Multifunction adjustment key (rear wheel)
