Trek Rail+ 5 5th Gen Viper Red electric mountain bike

25.28 kg - Aluminium frame - New Bosch Performance CX 85 Nm motor - 800 Wh battery - 160 mm travel (front/rear)

I choose my options

Colours

Size

Type of braking

MPN : 5329018 | EAN : 0197216100676 | Ref : 18855560002
€3,999.00 €4,999.00
In stock

Trek Rail+ 5 5th Gen Viper Red electric mountain bike

More details In stock

Trek Rail+ 5 5th Gen Viper Red electric mountain bike

€3,999.00 €4,999.00
Our advice

Equipped with a Bosch Performance CX motor and an 800Wh battery, this Trek Rail+ 5 will allow you to enjoy long mountain bike rides with complete peace of mind regarding range and technical ease!

Alexandre La.

Rider Elite XC for 5 years

The 5th-generation Rail+ 5 Trek is an e-MTB with an aluminium frame, designed for riding on dedicated MTB trails without leaving you exhausted on demanding climbs. It also lets you enjoy challenging descents thanks to its 160mm front fork and rear suspension, which will help you tackle the most demanding sections.

This 5th generation of the Trek Rail+ is fitted with the new Bosch Performance Line CX motor, delivering 85 Nm of torque, and paired with an 800 Wh battery, so tackling a series of long climbs will no longer be a problem! With four levels of assistance available, you’re bound to find the one that suits the terrain ahead of you. The battery is seamlessly integrated and removable, giving this e-MTB a sleek, minimalist look. What’s more, for those who love long days on the trails, you can optionally add the Bosch PowerMore 250 Wh battery kit to the bottle cage mount. This gives you a total battery capacity of 1050 Wh – more than enough to ensure you don’t run out of power on your long rides!

Finally, this Trek Rail 9.8 is fittedwith a high-performance Deore 1x12-speed drivetrain Shimano and precise, powerful Shimano MT4100 4-piston hydraulic brakes.

As you’ll have gathered, thisis an electric mountain bike ready to tackle all mountain bike trails, from the easiest to the most demanding, all with maximum physical and technical ease!

Bike shipping preparation

Technical specifications:

Frame / Fork / Rear Shock:
- Frame: Alpha Platinum aluminium, integrated removable battery (RIB 2.0), tapered head tube, internal cable routing, Motor Armor, adjustable-angle headset, Mino Link adjustable geometry, adjustable suspension ratio, 34.9 mm seat tube, ABP, UDH, Boost148, 12 mm thru-axle, 160 mm travel
- Fork: RockShox Psylo Gold RC, DebonAir spring, Isolator RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 160 mm travel
- Rear shock: RockShox Deluxe Select+ RT, 205 x 65 mm
- Maximum compatible fork travel: 180 mm

Motorisation:
- Motor: Bosch Performance Line CX, 25 km/h or 20 mi/h
- Battery: Bosch PowerTube 800 Wh,
smart system - Charger: Bosch standard 2 A, 230 V, smart system
- Control system: Bosch System Controller BRC3100, smart system

Gear system:
- Gear lever: Shimano Deore M6100, 12-speed
- Rear derailleur: Shimano Deore M6100, long cage
- Crankset: E*thirteen E*spec Plus, 160 mm long
- Cassette: Shimano Deore M6100, 10-51, 12-speed
- Chain: Shimano Deore M6100, 12-speed
- Max. chainring size: 36 teeth

Braking:
- Brakes: Shimano 4-piston hydraulic disc brakes, MT4100 lever, MT420 caliper
- Discs: Shimano RT66, 6-hole, 203 mm

Components:
- Saddle: Bontrager Verse P3, steel rails
- Telescopic seatpost: TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm
- Seatpost travel: 100 mm travel (S), 170 mm travel (M, L, XL)
- Seatpost length: 410 mm (S), 450 mm (M, L, XL)
- Handlebars: Alloy Bontrager, 31.8 mm, 15 mm rise, 750 mm width
- Grips: Bontrager XR Trail Comp, nylon lock-on
- Stem: Bontrager Comp, 31.8 mm, Blendr-compatible, 7 degrees, 50 mm length
- Pedals: VP-536, platform, nylon

Wheels:
- Front wheel: Bontrager Line, Tubeless Ready, 6-hole, Boost110, 15 mm thru-axle, 29 inches
- Rear wheel:  Bontrager Line, Tubeless Ready, Rapid Drive 108, 6 bolts, Boost148, 12 mm thru-axle, 27.5-inch
- Front tyre: Bontrager Gunnison Elite XR, tubeless-ready, rigid bead, 60 tpi, 29x2.40”
- Rear tyre: Bontrager Gunnison Elite XR, tubeless-ready, rigid bead, 60 tpi, 27.5x2.40”

General information:
- Sizes: S, M, L, XL
- Weight: 25.28 kg (size M)
- Max. weight: 136 kg
- Colour: Viper Red
- Product code: 5329018 (M)
- Brand: Trek

Colours red
Size M
Type of braking disc brakes
EAN 0197216100676
Supplier reference 5329018

Colours Size Type of braking Availability Price Supplier reference EAN
Web Stores
redSdisc brakesIn stockSold out€3,999.0053290170197216100683
redMdisc brakesIn stock
1 store
  • MV Store Villefranche-sur-Saône
€3,999.0053290180197216100676
redLdisc brakesTo order, contact us on 04.74.694.694Sold out€3,999.0053290190197216100669
redXLdisc brakesTo order, contact us on 04.74.694.694Sold out€3,999.0053290200197216100652
