Pinarello New Dogma F Disc Sram Red 12-speed DT Swiss ARC 1400 Luxter Blue road bike

The Pinarello New Dogma F Disc is the ultimate high-end bike; it is built around a TorayCa M40X carbon frame, a fibre that guarantees excellent lateral stiffness. The shape of the down tube is designed to improve the bike’s aerodynamic performance. Meanwhile, the Onda fork is slimmer and raked for greater stability and manoeuvrability at high speeds. As for the new Talon Ultra Fast handlebar-stem combo, it is lighter and more aerodynamic.

This Pinarello New Dogma F Disc G112 Luxter Blue is fitted with the Sram Red AXS 12-speed electronic groupset, which offers precise gear changes and high-performance disc braking in all conditions. Finally, the DT Swiss ARC 1400 wheels ensure maximum efficiency so you can perform at your best on all terrains, whether in the mountains or on the flat.

Please note that the image is for illustrative purposes only; this Pinarello New Dogma F Disc is well-equipped with a Sram Red AXS 12-speed groupset.

Technical specifications:

Frame:
- Frame: TorayCa M40X, TiCR Cable Routing, Italian BB
- Fork: NEW eTICR Onda Fork with ForkFlap™, 1.5" upper and lower steerer

Drivetrain:
- Crankset: SRAM Red AXS 12-speed
- Cassette: SRAM Red XG-1290, 12-speed
- Chain: SRAM Red 12-speed
- Grips: SRAM Red AXS 12-speed
- Front derailleur: SRAM Red AXS 12-speed
- Rear derailleur: SRAM Red AXS 12-speed

Braking:
- Brakes: SRAM Red 2-piston caliper, 160mm rotor
- Discs: 160 mm front / 160 mm rear

Components:
- Integrated handlebar and stem: Most Talon Ultra Fast
- Saddle: Most Lynx Ultrafast Superflow L Carbon Large 145mm
- Seatpost: Pinarello Aero seatpost with 3D-printed titanium top seatclamp and bolts
- Bottle cages: Trap PACF bottle cage ø 74mm, Fly Bottle Pinarello Bottle 550ml Black

Wheels:
- Wheels: DT Swiss ARC 1400 50 mm
- Tyres: Continental Grand Prix 5000S TR28-622

General information:
- Colour: G112 Luxter Blue
- Sizes: 43, 46.5, 50, 51.5, 53, 54, 55, 56, 57.5, 59.5, 62
- Weight: 6.77 kg (size 53)
- Brand: Pinarello
