BMC Kaius 01 LTD Gravel Bike Sram Red XPLR eTap AXS 12-speed Peacock Spider

Size 54 – Competition gravel

I choose my options

Colours

Size

Type of braking

MPN : 30005304 | EAN : 7630906508817 | Ref : 18787270003
€6,799.00 €11,999.00
In stock

BMC Kaius 01 LTD Gravel Bike Sram Red XPLR eTap AXS 12-speed Peacock Spider

More details In stock

BMC Kaius 01 LTD Gravel Bike Sram Red XPLR eTap AXS 12-speed Peacock Spider

€6,799.00 €11,999.00
Our advice

Designed for gravel racing, the BMC Kaius 01 LTD will be your favourite ally for achieving your best performance! A lightweight, fast and manoeuvrable bike.

Bruno V.

Road specialist

The 2025-generation Kaius 01 LTD gravel bike from BMC is designed to be the fastest on gravel tracks. Drawing direct inspiration from the BMC Teammachine SLR01 road bike, this model benefits from the very best technologies BMC, with specific adaptations for gravel riding. Notably, it features a specific geometry designed to provide comfort and efficiency, helping to absorb the numerous vibrations encountered on trails. Made entirely from carbon, it is designed to be lightweight, stiff and fast, whilst remaining robust enough to withstand the demands of gravel riding.

This is the top-of-the-range version; the bike is fitted with a SRAM Red eTap AXS 1x12-speed drivetrain, which shifts with ultra-precise and very smooth precision whatever the conditions. Zipp 303 Firecrest wheels are the icing on the cake, offering an aggressive look and unprecedented performance for maximum efficiency!

Bike shipping preparation

Technical specifications:

Frame:

- Frame: Kaius 01 Premium Carbon with Aerocore Design | ICS technology, stealth cable routing | Integrated Aerocore bottle cages | Stealth dropout design | TCC compliance rating | PF86 bottom bracket | Flat-mount disc | 12x142mm thru-axle,
2025 frame generation - Fork: Kaius 01 Premium Carbon | ICS technology, hidden cable routing | TCC race compliance level | Hidden dropout design | Flat-mount disc | 12x100mm thru-axle
- Axles: 12x100 mm/12x142 mm

Drivetrain:

- Gears: 1x12
- Crankset: Sram Red AXS 1 DUB Wide, 42T, power metre
- Cassette: Sram XPLR XG-1271 10-44T
- Chain: SRAM Red 12v
- Rear derailleur: SRAM Red AXS XPLR
- Shifters: SRAM Red eTap AXS HRD

Brakes:

- Brakes: SRAM Red eTap AXS HRD
- Rotors: SRAM Centerline X 160 mm

Components:

- Integrated handlebar/stem: ICS Carbon Evo - Full-carbon monoblock cockpit
- Seatpost: Kaius 01 Premium Carbon, D-shaped | 15 mm setback | Compatible with D-
mudguard - Saddle: Fizik Vento Argo R1 - 140 mm

Wheels:

- Wheels: Zipp 303 Firecrest, Zipp 303 hub, tubeless-ready
- Tyres: Pirelli Cinturato Gravel H 40 mm
- Max. tyre width: 44 mm

Accessories:

- Bottle cages: Aerocore Bottle Cages

General information:

- Sizes: 47/51/54/56/58/61
- Size geometries in the photo gallery
- Weight: 8.8 kg
- Max. weight: 120 kg
- ASTM classification: Level 2
- Colour: PEACOCK SPIDER
- Brand: BMC

Colours red
Size 54
Type of braking disc brakes
EAN 7630906508817
Supplier reference 30005304

Frame dimensions diagram
(mm) 47 51 54 56 58 61
A (Stack) 510 530 550 570 595 620
B (Reach) 390 397 401 405 410 414
C (Head tube length) 85 106 123 144 170 196
D (Bottom bracket axis - top of seat tube) 428 452 468 493 513 533
E (Horizontal length) 546 559 569 579 592 604

Colours Size Type of braking Availability Price Supplier reference EAN
Web Stores
red54disc brakesIn stock
1 store
  • MV Paris Herblay shop
€6,799.00300053047630906508817
red47disc brakesSold outSold out€6,799.00300053027630906508831
red51disc brakesSold outSold out€6,799.00300053037630906508824
red56disc brakesSold outSold out€6,799.00300053057630906508800
red58disc brakesSold outSold out€6,799.00300053067630906508794
red61disc brakesSold outSold out€6,799.00300053077630906508787
